The T-Shaped Slit Cast-Type Standard Shaft Support is engineered for industrial rotating shaft applications, offering robust stability and precision alignment. Constructed from high-grade cast iron, this support features a patented T-shaped slit design for effortless installation and secure adjustment, making it ideal for medium-to-heavy duty machinery.



Product Overview
Shaft Supports with Flange & Slit (Long Sleeve) are precision components designed to stabilize rotating shafts while offering enhanced load-bearing capacity and alignment control in compact spaces.

Product Features

1. Extended Sleeve Design
   • Long sleeve structure significantly boosts shaft contact area, improving grip strength (+40% vs. standard types) and radial support stability.
2. High-Precision Mounting
   • Guarantees ≤0.02mm perpendicularity for micron-level positioning accuracy, paired with slit-assisted quick installation to reduce assembly time by 30%.
3. Versatile Flange Options
   • Choose between space-efficient dual-surface-cut flanges or standard square flanges to match machine layouts.
4. Lightweight Durability
   • Aerospace-grade aluminum alloy construction (hard anodized finish) achieves 60% weight reduction versus steel counterparts without compromising strength.
5. Adaptive Installation
   • Slotted through-holes enable ±1.5mm positional fine-tuning during operation, allowing real-time shaft alignment corrections.
